产品详情


产品特点:

自动进料出料,配备先进的传动系统高速电主轴更安静,生产效率高,加工效率可达每分钟22根。全包围护罩结构,

采和集中除尘设计,外部粉尘小,清洁环保。独立式数控平台操作界面,操作安全方便。超大工作台面设计可满足长2080mm 宽150mm, 厚80mm 的工件加工。

Product  Features:

Automatic feeding and discharging,equipped with advanced transmission system high-speed motorized spindle quieter,

hiigh production efficiency,processing efficiency up to 22 per minute.Full enveloping shield structure,collection  and

centralized dust removal design,small external dust,clean and environmentally  friendly.Independent CNC platform

operation interface,safe and convenient operation.The large worktop design can meet the workpiece processing of

2080mm long,150mm wide and 80mm thick.


规格及型号 Specifications & ModelsMDK2214
木料最大加工板厚Maximum working plate thickness of wood80mm
木料最大加工板宽Maximum working board width of wood140mm
榫厚Tenon thickness50mm
榫宽Tenon width140mm
榫间最长Length between tenons2000mm
榫间最短Shortest tenon220mm
榫头最长Longest tenon40mm
外形尺寸Overall dimension4600*2350*2000mm
重量Weight2500KG
